This digital insulation resistance tester is designed for measuring insulation resistance and electrical parameters during maintenance, inspection, and troubleshooting tasks. Suitable for testing transformers, motors, cables, switchgear, and electrical installations, the instrument supports multiple test voltage settings to accommodate different measurement requirements. The backlit digital display provides clear visibility of readings, while integrated data storage allows measurement records to be saved for later review. An automatic discharge function assists after testing, and the durable housing with foldable support stand enables convenient operation in workshop, industrial, and field testing environments.

Key Features

• Features multiple insulation test voltage settings up to 2500V for a variety of electrical testing applications
• Provides storage capacity for up to 100 measurement records for documentation and review
• Includes a backlit digital display with 2000-count resolution for clear reading visibility
• Allows automatic discharge after testing to assist measurement procedures
• Offers a foldable support stand and protective housing for workshop and field use

Specifications

• Product Type: Digital Insulation Resistance Tester
• Primary Material: ABS and Silica Gel Housing
• Probe Material: PVC and Brass
• Color: Red and Black
• Product Dimensions: 18.05 x 14.0 x 7.0cm
• Product Weight: 0.64kg
• Insulation Resistance Range: 1 Megaohm to 200 Gigaohm
• Test Voltage Options: 250V, 500V, 1000V, 2000V, 2500V
• AC Voltage Range: 10V to 600V
• DC Voltage Range: 10V to 600V
• Data Storage Capacity: 100 Records
• Short Circuit Current: Approximately 1.8mA

Package Contents
1 x Digital Insulation Resistance Tester
1 x Test Lead
1 x Alligator Clip
1 x Signal Shielding Wire
1 x Storage Bag
1 x Carry Case
1 x Instruction Manual

Note
Batteries are not included. Requires 8 x AA batteries for operation.
